HMI Gateway, Screenless, Class I Div 2 Explosion-Proof, Quad-Core 1.6GHz, 4GB DDR4, 24VDC, Real-Time Data Exchange, Dual Gigabit Ethernet, Serial RS-232C/422/485, USB 2.0/3.0, Wi-Fi, 256GB SD, SCADAMaster-Designer, IP20
SKU:
iTP-GW-Ex
Weight:
3.80 LBS
Minimum Purchase:
1 unit
Explosion-proof HMI gateway for real-time data in hazardous locations.
The Autonics iTP Series explosion-proof (Ex) gateway is a hazardous-location certified, screenless HMI gateway for display-free applications in explosive-atmosphere areas certified to Class I, Division 2. Used for real-time data exchange and SCADA data collection between equipment and systems, it is powered by the same quad-core Cortex-A53 processor at 1.6 GHz with 4 GB of DDR4 memory and 16 GB of eMMC storage.
Key Features
Explosion-proof model for use in Class I, Division 2 hazardous areas
Quad-core Cortex-A53 CPU at 1.6 GHz with 4 GB DDR4 memory and 16 GB eMMC storage
Screenless gateway model for display-free, real-time data exchange between equipment and systems
Connects directly to databases (MS SQL Server, MySQL, MariaDB, Oracle, PostgreSQL) without separate servers or complex software
24V DC power supply
Dual Gigabit Ethernet (10/100/1000BASE-T), two serial ports (RS-232C/RS-422/RS-485), USB 2.0 and 3.0, and 2.4 GHz Wi-Fi
SD card support up to 256 GB (SDXC/SDHC)
Configured and monitored through SCADAMaster-Designer, VNC, and the built-in web tool
DIN rail mounting and 100 x 100mm VESA wall mounting; aluminum die-cast case; IP20-rated
Certifications
CE
UKCA
cULus (UL Listed)
KC
KCs
Hazardous-location certified: Class I, Division 2, Groups A, B, C, D, T5
