111683
111683
Sensor, Ultrasonic,Top Mount, 90-1500 mm Range
Sensor, Ultrasonic,Top Mount, 90-1500 mm Range
Pepperl+Fuchs

111683

Alt: UB1500-F42-UK-V95

$413.56

Ultrasonic Sensor, Top Mount, 90-1500mm Range, 1 Relay Output, NO/NC Selectable, 5-Pin V95 connector (7/8"-16 UN 2A), Returns of This Item Must Be Approved by Manufacturer

Minimum Purchase:
1 unit
Adding to cart… The item has been added
111683
Sensor, Ultrasonic,Top Mount, 90-1500 mm Range
Sensor, Ultrasonic,Top Mount, 90-1500 mm Range
111683
Sensor, Ultrasonic,Top Mount, 90-1500 mm Range
Sensor, Ultrasonic,Top Mount, 90-1500 mm Range
Description
Sensor, Ultrasonic,Top Mount, 90-1500 mm Range 1 relay output, NO/NC selectable, V95 con, 5-pin

Features Include:

Sensing Range

  • 70 - 1500 mm

Adjustment Range

  • 90 - 1500 mm

Dead Band

  • 0 - 70 mm

Standard Target Plate

  • 100 mm x 100 mm

Transducer Frequency

  • Approximately 175 kHz

Fusing

  • ≤ 3 A Slow-blow fuse in accordance with IEC 60127-2 Sheet 5 required. Recommendation: after a short circuit, check that the device is functioning correctly.

Operating Voltage

  • 22 - 253 V DC

Output Type

  • 1 relay output

Rated operating current

  • 3 A

Connection Type

  • 5-pin V95 connector (7/8"-16 UN 2A)

Ambient Temperature

  • -25 - 70 °C (-13 - 158 °F)
Accessories
!
✓
