Sensor, Ultrasonic,Top Mount, 400-6000 mm Range
Sensor, Ultrasonic,Top Mount, 400-6000 mm Range
Pepperl+Fuchs

134009

Alt: UB6000-F42-I-V15

$404.50

Ultrasonic Sensor, Top Mount, 400-6000mm Range, 1 Analog Output, 4 to 20 mA, V15 (M12x1) 5-Pin, Returns of This Item Must Be Approved by Manufacturer

Minimum Purchase:
1 unit
Adding to cart… The item has been added
134009
Sensor, Ultrasonic,Top Mount, 400-6000 mm Range
Sensor, Ultrasonic,Top Mount, 400-6000 mm Range
134009
Sensor, Ultrasonic,Top Mount, 400-6000 mm Range
Sensor, Ultrasonic,Top Mount, 400-6000 mm Range
Description
Sensor, Ultrasonic,Top Mount, 400-6000 mm Range 1 analog output 4 ... 20 mA, V15 (M12x1) 5-pin

Features Include:

Sensing Range

  • 350 - 6000 mm

Adjustment Range

  • 400 - 6000 mm

Dead Band

  • 0 - 350 mm

Standard Target Plate

  • 100 mm x 100 mm

Transducer Frequency

  • Approximately 65 kHz

Operating Voltage

  • 10 - 30 V DC, ripple 10 %SS

Output Type

  • 1 analog output 4 ... 20 mA

Connection Type

  • Connector M12 x 1, 5-pin

Ambient Temperature

  • -25 - 70 °C (-13 - 158 °F)
