Sensor, Ultrasonic,Side Mount, 50-500 mm Range
Pepperl+Fuchs

133982

Alt: UB500-F42S-E6-V15

$309.92

Ultrasonic Sensor, Side Mount, 50-500mm Range, 2 Switch Outputs PNP, NO/NC Selectable, V15 5-Pin, Returns of This Item Must Be Approved by Manufacturer

Minimum Purchase:
1 unit
Adding to cart… The item has been added
133982
Sensor, Ultrasonic,Side Mount, 50-500 mm Range
133982
Sensor, Ultrasonic,Side Mount, 50-500 mm Range
Description
Sensor, Ultrasonic,Side Mount, 50-500 mm Range 2 switch outputs PNP, NO/NC selectable, V15 5-pin

Features Include:

Sensing Range

  • 30 - 500 mm

Adjustment Range

  • 50 - 500 mm

Dead Band

  • 0 - 30 mm

Standard Target Plate

  • 100 mm x 100 mm

Transducer Frequency

  • Approximately 390 kHz

Rated operating current

  • 200 mA , short-circuit/overload protected

Operating Voltage

  • 10 - 30 V DC , ripple 10 %SS

Output Type

  • 2 switch outputs PNP, NO/NC selectable

Connection Type

  • Connector M12 x 1 , 5-pin

Ambient Temperature

  • -25 - 70 °C (-13 - 158 °F)
