097968
097968
Sensor, Ultrasonic, 30mm, 120mm to 2m adj range
Pepperl+Fuchs

097968

Alt: UB2000-30GM-E4-V15

$356.20

Ultrasonic Sensor, 30mm, 120mm to 2m Adjustable Range, Single Switch Point Output, NPN, Returns of This Item Must Be Approved by Manufacturer

Minimum Purchase:
1 unit
Adding to cart… The item has been added
097968
Sensor, Ultrasonic, 30mm, 120mm to 2m adj range
097968
Sensor, Ultrasonic, 30mm, 120mm to 2m adj range
Description
Sensor, Ultrasonic, 30mm, 120mm to 2m adj range Single Switch Point Output, NPN

Features Include:

Sensing Range

  • 80 - 2000 mm

Adjustment Range

  • 120 - 2000 mm

Dead Band

  • 0 - 80 mm

Standard Target Plate

  • 100 mm x 100 mm

Transducer Frequency

  • Approximately 180 kHz

Operating Voltage

  • 10 - 30 V DC , ripple 10 %SS

Input Type

  • 1 program input,
    operating range 1: -UB ... +1 V, operating range 2: +4 V ... +UB
    input impedance: > 4.7 kΩ; program pulse: ≥ 1 s

Output Type

  • 1 switching output E5, PNP NO/NC, programmable

Rated operating current

  • 200 mA , short-circuit/overload protected

Connection Type

  • Connector M12 x 1 , 5-pin

Ambient Temperature

  • -25 - 70 °C (-13 - 158 °F)
