DL-S200P

Photo Sensor, Fixed Field Reflective, Relay, 200/1000mm, Infrared LED, Terminal Block

Features Include:

• Long distance type 1m or 2m
• Terminal board connection ensures open space at writing
• Detection Distance: 0.2-2m
• Detection Method: Limited range reflective
• Setting Distance: 0.2 - 2m (with 200×200mm white drawing paper)
• Power Supply: 12 - 24V DC ±10‚àö√Ƭ¨‚à´‚àö√± / Ripple 10% or less
• Operation Mode: Light ON/Dark ON selectable (with switch)
• Volume (VR): NEAR/FAR: Optical distance adjustment
• Response Time: 20ms or less
• Hysteresis: 10% of detecting distance or less
• Light Source (light wavelength): Infrared LED (880nm)
• Light Receiving Element: 2 segment photodiode
• Material: Body: polycarbonate / Front, terminal cover: acrylic
• Connection: Terminal block

Current Consumption:

• DC Power Supply: 30 mA or less
• AC Power Supply: 4 W or less

Indicator:

• OP.L: operation indicator (red LED)
• UP: stability indicator (green LED)

Switch:

• Light ON/Dark ON selector switch
• L.ON: Light ON | D.ON: Dark ON

Output Mode:

• Relay output 1a 3A 250 V 750 VA AC or less resistive load
• 3A 30 V 90 W DC or less resistive load

Environmental Factors:

• Ambient Light: 10,000 lx or less
• Ambient Temperature: -25 - +55°C (non-freezing)
• Ambient Humidity: 35 - 85%RH (non-condensing)
• Vibration: 10-55 Hz / 1.5 mm double amplitude / 2 hours each in 3 directions
• Shock: 500 m/s2 / 3 times each in 3 directions
• Dielectric: 1,000 VAC for 1 minute
• Insulation Resistance: 500 VDC, 20 MΩor higher
