439-010-55

Features Include:

• 32 tones for a diverse range of applications
• Application-specific sound output setting up to 105 dB
• 2 tones can be triggered externally
• Optical and acoustic signal can be separately triggered for two-stage signalling

Connection

• Terminal clamp with wire protection single wire / 0,25-1,5mm² with ferrule

Cable entry

• Cable gland M20 x 1.5 (not included)

Sound output

• 105dB

Voltage

• 9 - 60V DC

Tone frequency

• approx. 300 - 4000 Hz

Temperature range

• -25°C...+70°C

Housing material

• ABS

Width

• 138 mm

Height

• 136 mm

Depth

• 119 mm

• Werma 439 X#0 XX Datasheet
• Werma 439 X#0 XX Operating Instructions
• Werma 2017 Product Catalog
