Available Now! PESWS-B50V24AX-RM71
Available Now! (1 in stock)
Weg

PESWS-B50V24AX-RM71

Alt: 14970652, Alternative for PESWS-50V24AX-RM38 (10212723)

$256.08

Enclosed Starter, 50 Amp (50A) CWB Contactor, 208-240VAC Coil Voltage, Start/Stop, 32-50A Overload Range, Single Phase, NEMA 4X, Non-Metallic, Non-Reversing, Non-Combination Across the Line Starter, M06 Box Dimensions: 13 x 7.5 x 5.6 (HWD)

Weight:
10.00 LBS
Minimum Purchase:
1 unit
Adding to cart… The item has been added
Non-reversing, non-combination NEMA 4X magnetic starter that meets IEC standards and UL horsepower ratings!
Description

WEG offers a full line of magnetic starters that feature components that meet IEC design standards and UL horsepower ratings plus use WEG contactors and overload relays.

Magnetic starters are designed to protect and operate motors.

There are a number of starters available from WEG:

Non-combination starters:

  • ESW series is metallic, NEMA 1, across the line starter, three phase
  • ESWS series is metallic, NEMA 1, non-reversing, across the line starter, single phase
  • ESWX series is metallic, NEMA 7/9, explosion proof starters
  • PESW series is non-metallic, NEMA 4X, across the line starter, three phase
  • PESWS series is non-metallic, NEMA 4X, across the line starter, single phase

Combination starters:

  • ESWC series
  • ESWE series
  • ESWF series

Marshall Wolf Automation is your authorized WEG distributor!

Effective May 2023: WEG Electric has announced that their ESW and ESWS series will now use the WEG CWB series of contractors, replacing the currently used CWM series of contactors.




Accessories
Check any items you would like to add to your cart, and then tap the ‘Add Selection to Cart’ button.
Add Selection to Cart

Weg

PESW-B50V24AX-R71

Enclosed Starter, 50 Amp (50A) CWB Contactor, 180-208VAC (50Hz) / 208-240VAC (60Hz), A-On-Off Button, 32-50A (RW67) Overload Range, Three Phase, NEMA 4X, Non-Metallic, Non-Reversing, Non-Combination Across the Line Starter

$336.98

Weg

PESWS-B50V24AX-RM70

Enclosed Starter, 50 Amp (50A) CWB Contactor, 208-240VAC Coil Voltage, Start/Stop, 25-40A Overload Range, Single Phase, NEMA 4X, Non-Metallic, Non-Reversing, Non-Combination Across the Line Starter, M06 Box Dimensions: 13 x 7.5 x 5.6 (HWD)

$256.08

Weg

PESWS-B50D15EX-RM71

Enclosed Starter, 50 Amp (50A) CWB Contactor, 120VAC Coil Voltage, Reset Only, 32-50A Overload Range, Single Phase, NEMA 4X, Non-Metallic, Non-Reversing, Non-Combination Across the Line Starter, M06 Box Dimensions: 13 x 7.5 x 5.6 (HWD)

$250.26

Weg

PESWS-B50V24EX-RM71

Enclosed Starter, 50 Amp (50A) CWB Contactor, 208-240VAC Coil Voltage, Reset Only, 32-50A Overload Range, Single Phase, NEMA 4X, Non-Metallic, Non-Reversing, Non-Combination Across the Line Starter, M06 Box Dimensions: 13 x 7.5 x 5.6 (HWD)

$250.26

Weg

PESWS-B50D15AX-RM71

Enclosed Starter, 50 Amp (50A) CWB Contactor, 120VAC Coil Voltage, Start/Stop, 32-50A Overload Range, Single Phase, NEMA 4X, Non-Metallic, Non-Reversing, Non-Combination Across the Line Starter, M06 Box Dimensions: 13 x 7.5 x 5.6 (HWD)

$256.08
