Available Now!
Available Now!
(1 in stock)
124311
Alt: NBB5-18GM60-WS
$157.98
Inductive Proximity Sensor, 2-Wire AC, Flush, 20-253V, 5mm Range, NO, 200mA, 2m PVC Cable, Nickel Plated Brass Housing, PBT Sensing Face, Ambient Temperature: -25 to 70 °C (-13 to 158 °F), IP67
- Minimum Purchase:
- 1 unit
Description
Features Include:
- Switching function: Normally open (NO)
- Output type: Two-wire
- Rated operating distance: 5 mm
- Installation: flush
- Output polarity: AC
- Assured operating distance: 0 - 4.05 mm
- Actual operating distance: 4.5 - 5.5 mm typ. 5 mm
- Output type: 2-wire
- Operating voltage: 20 - 253 V
- Switching frequency: 0 - 20 Hz
- Connection type: Cable PVC , 2 m
- Housing material: brass, nickel-plated
- Sensing face: PBT
- Degree of protection: IP67
Technical Information:
