Sprecher and Schuh
V7-EA35
End Anchor, Normal Duty, DIN Rail Mount, for V7-W3 through V7-W35 Terminal Blocks, V7 Series
$0.81
V7-W3
$1.27
Terminal Block, Feed-Through, 2.5mm² (22-14 AWG), 20A UL, 600VAC/VDC, 1 Circuit, 5mm Wide, Gray, Screw Clamp, DIN Rail Mount, V7 Series
- Weight:
- 0.10 LBS
- Minimum Purchase:
- 1 unit
Description
The Sprecher + Schuh V7 IEC terminal block series is built around easy wiring, secure connections, and durability for control panel wiring. Feed-through blocks mount on DIN rail and use stainless steel clamping screws with nickel-plated current bars, while a cone-shaped wire guide helps speed conductor insertion.
Key Features
- Feed-through screw terminal blocks for DIN rail mounting
- Stainless steel screws and nickel-plated current bars
- Polyamide 6.6 housing rated for 90°C continuous and elastic down to -40°C
- Recessed metal parts for a touch-safe design
- Rated 600V AC/DC (UL) and 800V (IEC)
- Matching V7 end barriers, end anchors, and center jumpers available
Certifications
- UL Recognized (UL 1059)
- CSA certified (C22.2 No. 158)
- CE
- IEC 60947-7-1
Accessories
Check any items you would like to add to your cart, and then tap the ‘Add Selection to Cart’ button.
$41.40
Sprecher and Schuh
V7-W4
Terminal Block, Feed-Through, 4mm² (22-10 AWG), 30A UL, 600VAC/VDC, 1 Circuit, 6mm Wide, Gray, Screw Clamp, DIN Rail Mount, V7 Series
$1.45
$0.57
Sprecher and Schuh
V7-W16S
Terminal Block, Feed-Through, 16mm² (14-4 AWG), 85A UL, 600VAC/VDC, 1 Circuit, 11mm Wide, Gray, Screw Clamp, DIN Rail Mount, V7 Series
$3.24
