MPLN-Z01-5L

Features Include:

• Application: Working light, Enclosure box, Semiconductor machinery
• Type :Bar type lamp
• Power supply: 12VDC
• Type: Z-Type, Terminal block + Built-in ON/OFF switch type
• Light Color: Natural White
• Strip Length: 500mm
• Connection: 60227 KS IEC 53, 2CX0.7-Exposure length: 400mm
• Material: Housing-PC resin (milky white), Cover-ABS resin(ivory),
• Bracket: - PC resin (transparent)
• Withstand voltage AC: 1500VAC 60Hz for 1 minute / DC: 500VAC 60Hz for 1 minute
• Insulation resistance: 100MΩ or more (500VDC Mega between all terminals and case)
• Vibration 10~55Hz (cycle 1 minute): Amplitude 0.75mm X, Y, Z 1hour

Technical Information:

• Menics MPL Series Bar Tyle LED Panel Lamp Technical Data
