IR08.P03S-F46.PO1Z.7SL
10 available from manufacturer (as of 10/28/2026)
Baumer

IR08.P03S-F46.PO1Z.7SL

Alt: 11148757

$169.20

Inductive Proximity Sensor, Ø8x46mm, Flush, SS, 6-36VDC, 3mm Range, PNP NO

Weight:
0.50 LBS
Minimum Purchase:
1 unit
Adding to cart… The item has been added
Description
Inductive Proximity Sensor

Features Include:

  • Mounting Type: Flush
  • Special Type: Enhanced distance (GammaProx)
  • Nominal Sensing Distance Sn: 3 mm
  • Voltage Supply Range: 6 - 36 VDC
  • Current Consumption Max. (no load): 10 mA
  • Output Current: < 100 mA
  • Hysteresis: 3 - 20 % of Sr
  • Switching Frequency: < 2 kHz
  • Output Circuit: PNP make function (NO)
  • Connection: Connector M8
  • Operating Temperature: -25 - 75 °C
  • Protection Rating: IP 67
