ADAM-4542+-BE
Alt: ADAM 4000 Series
$626.90
RS485 I/O Module, Fiber Optic to RS-232/422/485 Converter, Single Mode, 10-30VDC, 1 x SC Fiber Connector, 1 x 10-pin Plug-in Screw Terminal, ADAM-4000 Series
- Weight:
- 1.00 LBS
- Minimum Purchase:
- 1 unit
Description
Advantech was founded in 1983 by three ex-Hewlett Packard engineers and released the first industrial PC (IPC-600) in 1990.
Features Include:
- Input Voltage: 10~30 VDC
- Power Input Unregulated: 12 ~ 24 VDC
- Power Consumption: 3 W @ 24 VDC
- Optical Power Budget (Attenuation): 15 dB
- Transmission Distance: 15 km
- Transmission Mode: Single mode (Send and Receive)
- Wavelength: 1310 nm
- Communication Mode: Asynchronous
- Connectors: 1 x SC fiber connector, 1 x 10-pin plug-in screw terminal
- Baud Rate (bps): 1200 bps~921.6 kbps
- Converter/Repeater: Fiber Optic to RS-232/422/485
- Operation mode: Point-to-Point, Redundant and Ring(half-duplex)
- Half/Full-duplex, bidirectional transmission mode
- Automatic RS-485 data flow control
- LED indicator to monitor status
Technical Information:
- Advantech ADAM-4541 / 4542+ / 4561/4562 Module Technical Data
- Advantech ADAM-4000 Series User Manual
- Advantech ADAM-4000 Series Access Port Instructions
- Advantech ADAM-4000 Series AIO Calibration Instructions
- Advantech ADAM-4000 Series Reconnection Instructions
- Advantech ADAM-4000 Series DO Voltage/Current Datasheet
- Advantech ADAM-4000 Series Tolerance Range Datasheet
