6490642046
Alt: 649.0642.046, MAK-4256-3
$132.88
Magnetic Switch Non-Contact, Part of Safety System Can Be Used w/Safety Evaluation Unit (MUZ Series)
- Minimum Purchase:
- 1 unit
Description
Features Include:
- Assured Operating Distance: 4 mm
- Switching Element Function: 2 x N.C. for the safety circuit, 1 x N.O. for signalling purposes (PK/GY; not coded)
- Max. Voltage: 130 V DC
- Ambient Temperature (min/max): -25°C/+70°C
- Protection Class: IP67
- Enclosure: PA6, black; encapsulated reed contact
- Termination Type: Cable 6 x 0,25 mm² x 3 m 5 %; PVC - Outer jacket, grey
