LSLV0004M100-SEONNA

Our LS Electric M100 series is ideal for small motor applications! These single phase input/3 phase output drives are available in 200-240V or 115V.

• DIN rail mount
• Meets UL 60800-5-1
• Built-in C2 EMC filter
• Side by side installation
• Easy connection with RJ45 port
• IP20
• 2 year warranty
• Single phase input/3 phase output

Marshall Wolf Automation is an authorized stocking distributor for LS Electric.

Features Include:

• Rated Current Input: 3.7 A
• Input Frequency: 50~60Hz(±5%)
• Rated Input Voltage: 1 phase 200-240Vac(-15% to +10%)
• Rated Output Capacity: 0.95 kVA
• Rated Output Current: 2.4 A
• Rated Output Frequency: 0~400Hz
• Rated Output Voltage: 3 phase 200-240V
• Built-in C2 EMC Filter
• New UL 61800-5-1 Design - Enhanced isolation circuit
• Built-in DB unite: ≥ 1.5kW
• Modbus in advanced I/O type
• DIN-rail mountable
• Side-by-side installation
• Easy connection with RJ45 port
• Modbus/Smart copier/Remote keypad/DriveView 9

Technical Information:

• LSIS M100 Micro Drive Brochure
• LSIS M100 Micro Drive Start-Up Guide
• LSIS M100 Micro Drive Simple User Manual
• LSIS M100 Micro Drive User Manual
