35-M010
Dongan

35-M010

Alt: 35-M010

$238.49

Buck-Boost Transformer, .100kVA, Primary: 120/240VAC, Secondary: 12/24VAC, 50/60Hz, Ventilated NEMA Type 1 Construction, Dual Primary/Dual Secondary Buck-Boost or Isolation Transformer, UL/cUL, Buck-Boost Series

Weight:
5.00 LBS
Minimum Purchase:
1 unit
Adding to cart… The item has been added
Simple, economical fix for chronically low or high line voltage
Description

The Dongan Buck-Boost Series transformer is a single phase, four-winding transformer used to correct consistently low or high line voltage, matching supply voltage to the load's required nominal voltage.

Key Features

  • Dual primary (120x240V or 240x480V) and dual secondary (12/24V, 16/32V, or 24/48V) windings
  • Corrects voltage variation of approximately 5% to 27% between supply and load
  • Common uses include boosting 208V lines to 230/240V and 240V to 277V for lighting loads
  • Also usable as a low voltage isolation transformer on 12-48V circuits

Certifications

  • UL and cUL Listed
