The Dongan Buck-Boost Series transformer is a single phase, four-winding transformer used to correct consistently low or high line voltage, matching supply voltage to the load's required nominal voltage.
Key Features
Dual primary (120x240V or 240x480V) and dual secondary (12/24V, 16/32V, or 24/48V) windings
Corrects voltage variation of approximately 5% to 27% between supply and load
Common uses include boosting 208V lines to 230/240V and 240V to 277V for lighting loads
Also usable as a low voltage isolation transformer on 12-48V circuits
Transformer, .150kVA, Primary: 240x480VAC, Secondary: 120VAC, 50/60Hz, UL Class 105C Insulation, NEMA Type 1, Wall Mount, Ventilated, Fused, UL/cUL, 35 Series
Transformer, .100kVA, Primary: 240x480VAC, Secondary: 120VAC, 50/60Hz, UL Class 105C Insulation, NEMA Type 1, Wall Mount, Ventilated, Fused, UL/cUL, 35 Series
Transformer, .500kVA, Primary: 600VAC, Secondary: 120/240VAC, 50/60Hz, UL Class 105C Insulation, NEMA Type 1, Wall Mount, Ventilated, UL/cUL, 35 Series
Transformer, .100kVA, Primary: 600VAC, Secondary: 120/240VAC, 50/60Hz, UL Class 105C Insulation, NEMA Type 1, Wall Mount, Ventilated, UL/cUL, 35 Series
