IDEC
HW1R-2TW-PS-U
Sub-Assembled Operator, 22mm, Selector Pushbutton, 2 Positions, Circuit Code T, White
$11.49
Ships from manufacturer in ~56 days (as of 10/13/2026)
HW1R-2AG-PS-U
Alt: HW Series, Updated Design, This Item Replaced HW1R-2AG
$11.49
Sub-Assembled Operator, 22mm, Selector Pushbutton, 2 Positions, Circuit Code A, Green
- Weight:
- 0.04 LBS
- Minimum Purchase:
- 1 unit
Description
The IDEC HW Series selector pushbutton sub-assembled operator combines selector and pushbutton functions in a single 22mm HW Series operator, reducing the number of devices needed on a control panel. Two-position versions are available in multiple circuit codes and button colors depending on model. The operator is part of IDEC's updated HW Series design and pairs with the new HW-CN connecting units.
Key Features
- Fits 22mm panel mounting holes
- Selector and pushbutton functions in one operator help conserve panel space
- 2-position operation
- Circuit codes A, D, E, F, N, and T define the switching pattern, depending on model
- Black, green, red, blue, white, and yellow button colors, depending on model
- Universal operator design works with both screw terminal and push-in connecting units, so the terminal style can be changed by replacing only the rear connecting unit
- Use with updated HW-CN connecting units; updated operators are not compatible with previous-generation connecting units
- HW Series switches are rated UL Type 4X and IP65
- Part of IDEC's updated HW Series design, which keeps the functionality, electrical ratings, and certifications of the previous generation
Accessories
Check any items you would like to add to your cart, and then tap the ‘Add Selection to Cart’ button.
IDEC
HW1R-2EY-PS-U
Sub-Assembled Operator, 22mm, Selector Pushbutton, 2 Positions, Circuit Code E, Yellow
$11.49
IDEC
HW1R-2EG-PS-U
Sub-Assembled Operator, 22mm, Selector Pushbutton, 2 Positions, Circuit Code E, Green
$11.49
IDEC
HW1R-2FS-PS-U
Sub-Assembled Operator, 22mm, Selector Pushbutton, 2 Positions, Circuit Code F, Blue
$11.49
IDEC
HW1R-2DG-PS-U
Sub-Assembled Operator, 22mm, Selector Pushbutton, 2 Positions, Circuit Code D, Green
$11.49
