Autonics
BM200-DDT
Photoelectric Sensor, Diffuse Reflective, 200mm, Transparent/Translucent/Opaque Material, 12-24VDC
$66.00
5 available from manufacturer (as of 11/2/2026)
BYD100-DDT
$59.00
Photoelectric Sensor, Diffuse Reflective, 100mm, Translucent/Opaque, 12-24VDC
- Weight:
- 0.25 LBS
- Minimum Purchase:
- 1 unit
Description
Sensor, Photoelectric, Diffuse Reflective, 100mm, Translucent/Opaque, 12-24VDC
Features Include:
- Sensing type: Diffuse reflective type
- Sensing distance: 100mm
- Sensing target: Opaque, Translucent material
- Light source: Infrared LED
- Power supply: 12-24VDC ±10%(ripple P-P: max. 10%)
- Response time: Operation: Max. 3ms,
- Return: Max. 100ms
- Operation mode: Light ON
- Control output: NPN open collector
- Connection type: Cable type(Ø3.5, 2m)
- Material Case: Acrylonitrile butadiene styrene, Sensing part: Acrylic, Bracket: Steel Plate Cold Commercial, Bolt: Steel Chromium molybdenum, Nut: Steel Chromium molybdenum, Sleeve: Brass, Ni-plate
Accessories
Available Now!
Check any items you would like to add to your cart, and then tap the ‘Add Selection to Cart’ button.
Autonics
BH1M-DDT
Photoelectric, Diffuse Reflective, 1m, 12-24VDC, NPN/PNP, IP67, Front or Side Mount, Compact, Light Source: Infrared
$78.00
$75.00
$54.01
$56.00
