Transponder-Coded Safety Switch, w/Guard Locking and Integrated Evaluation Electronics, IO-Link Gateway GWY-CB or ESM-CB, Open-Circuit, M12 Plug Connectors, Unicode, Approach directions A, B and C (delivery state)
SKU:
166702
Weight:
2.44 LBS
Minimum Purchase:
1 unit
Euchner CTA metal transponder guard locking switch with 8,000 N locking force
The Euchner CTA transponder-coded safety switch with guard locking secures heavy safety doors and flaps with a locking force of up to 8,000 N in a very slim, robust metal housing. It combines the operating principle of an electromechanical guard locking switch with transponder-coded safety technology, so a single CTA achieves Category 4/PL e according to EN ISO 13849-1 without additional fault exclusion and meets the requirements of EN ISO 14119. Integrated guard locking and guard lock monitoring allow use for both personnel and process protection.
Key Features
Guard locking force up to 8,000 N
Metal housing with metal head; IP65/IP67/IP69/IP69K degree of protection
Approach from four directions; integrated funnel eases actuator insertion on unstable doors
Faulty closure protection prevents the safety outputs switching on if the actuator is not fully inserted
BR versions: series connection of up to 20 CTA or other Euchner BR system family devices
Communication functions in combination with an IO-Link gateway GWY-CB or ESM-CB
Mounting compatible with existing safety switches; retrofittable escape release
