Locking set MGB-L1H-APA... Spring Force Guard Locking With Guard Lock Monitoring, 3 Illuminated Pushbuttons, RC18 Plug Connector, M12 Plug Connector For Enabling Switch, Unicode
SKU:
116430
Weight:
5.14 LBS
Minimum Purchase:
1 unit
Safety gate boxes for machine guard door protection.
The Euchner MGB-AP multifunctional gate box is a transponder-coded guard locking system for protecting safety doors on machines and installations. The MGB system combines the safety switch, handle and bolt, and its modular design lets the interlocking or locking module become a small operator panel with E-stop, pushbuttons and other controls. The AP system family is intended for individual safety doors where series connection is not required, which saves wiring, and it connects to almost any safe evaluation unit or safe control system.
Key Features
Guard locking by spring force, released by solenoid force (closed-circuit current principle, mechanically locked)
Individual device connection to safe evaluation units or safe control systems
Guard locking controlled via IMP control input on the PLC (only 3 mA)
Monitoring outputs for door position, bolt tongue, guard locking and diagnostics
Connection via M20 x 1.5 cable entry or HC26, M23 (RC18) or M12 plug connector, depending on version
Handle module and interlocking/locking module form the basic system, with integrated lockout mechanism
Transponder technology up to PL e according to EN ISO 13849-1
Optimized for mounting on profiles, with alignment tolerance of ±4 mm in x and ±5 mm in z direction
Diagnostics via 4 status LEDs
Stable metal stop prevents damage when the bolt tongue is extended
Optional escape release with door handle; optional pushbuttons and indicators integrated in the housing
