56.OA11.2422C
$45.99
Safety Relay, 24V, 16.8 to 33.6V Range, 960 ? Coil Resistance, 2NO/2NC, Contact Material: AgSnO2+.2µmAu, Minimum Order of 30 (per Pack), Price per Piece
- Weight:
- 0.25 LBS
- Minimum Purchase:
- 30 units
Description
Altech Corporation was founded in 1984 and is a master distributor for a complete line of industrial automation components. Altech has been a long-time partner of ours and consistently brings high quality and unique products to the market.
They are located in Flemington, New Jersey and are ISO 9001:2015 certified.
Features Include:
- Nominal Coil Voltage: 24V DC
- Voltage Range: 16.8 - 33.6V
- Coil Power Dissipation: 0.6 W
- Max. Switching Voltage: 250V DC, 400 V AC
- Max. Switching Current: 8 A
- Max. Switching Power — DC: 200W
- Max. Switching Power — AC: 2000VA
- Contact Switching Rate: 10 operations per second
- Relay Operate Time: 20 ms
- Relay Release Time: 6 ms
- Protection Rating: IP 40
- Contact Arrangements: 2NO/2NC, 3NO/1NC
- Contact Material: AgNi10+0.2μmAu, AgSnO2+0.2μmAu, AgNi10+5μmAu
- Ambient Temperature: -40 - +85°C
- Cover Material: Thermoplast
Technical Information:
