Transformers

Dongan

63-2920SH

63-2920SH

Transformer, 20kVA, Primary: 575VAC, Secondary: 460Y/266VAC, 60Hz, 3 Phase, Electrostatic Shield, NEMA Type 3R Ventilated, Vibration Dampening Pads, Exempt From DOE TP1, UL/cUL, 63 Series (Motor Drive Isolation)

Dongan

63-2927SH

63-2927SH

Transformer, 27kVA, Primary: 575VAC, Secondary: 460Y/266VAC, 60Hz, 3 Phase, Electrostatic Shield, NEMA Type 3R Ventilated, Vibration Dampening Pads, Exempt From DOE TP1, UL/cUL, 63 Series (Motor Drive Isolation)

Dongan

63-2934SH

63-2934SH

Transformer, 34kVA, Primary: 575VAC, Secondary: 460Y/266VAC, 60Hz, 3 Phase, Electrostatic Shield, NEMA Type 3R Ventilated, Vibration Dampening Pads, Exempt From DOE TP1, UL/cUL, 63 Series (Motor Drive Isolation)

Dongan

63-2940SH

63-2940SH

Transformer, 40kVA, Primary: 575VAC, Secondary: 460Y/266VAC, 60Hz, 3 Phase, Electrostatic Shield, NEMA Type 3R Ventilated, Vibration Dampening Pads, Exempt From DOE TP1, UL/cUL, 63 Series (Motor Drive Isolation)

Dongan

63-2951SH

63-2951SH

Transformer, 51kVA, Primary: 575VAC, Secondary: 460Y/266VAC, 60Hz, 3 Phase, Electrostatic Shield, NEMA Type 3R Ventilated, Vibration Dampening Pads, Exempt From DOE TP1, UL/cUL, 63 Series (Motor Drive Isolation)

Dongan

63-2963SH

63-2963SH

Transformer, 63kVA, Primary: 575VAC, Secondary: 460Y/266VAC, 60Hz, 3 Phase, Electrostatic Shield, NEMA Type 3R Ventilated, Vibration Dampening Pads, Exempt From DOE TP1, UL/cUL, 63 Series (Motor Drive Isolation)

Dongan

63-2975SH

63-2975SH

Transformer, 75kVA, Primary: 575VAC, Secondary: 460Y/266VAC, 60Hz, 3 Phase, Electrostatic Shield, NEMA Type 3R Ventilated, Vibration Dampening Pads, Exempt From DOE TP1, UL/cUL, 63 Series (Motor Drive Isolation)

Dongan

63-2993SH

63-2993SH

Transformer, 93kVA, Primary: 575VAC, Secondary: 460Y/266VAC, 60Hz, 3 Phase, Electrostatic Shield, NEMA Type 3R Ventilated, Vibration Dampening Pads, Exempt From DOE TP1, UL/cUL, 63 Series (Motor Drive Isolation)

Dongan

63-30-2996

63-30-2996

Transformer, 30kVA, Primary: 400VAC, Secondary: 600Y/347VAC, 60Hz, 3 Phase, Electrostatic Shield, Aluminum Windings, UL Class 220C Insulation, NEMA Type 3R Ventilated Floor Mount, DOE 2016 Compliant, UL/cUL, 63/73 Series (Vanguard)

Dongan

63-30-3117

63-30-3117

Transformer, 30kVA, Primary: 415VAC, Secondary: 208Y/120VAC, 60Hz, 3 Phase, Electrostatic Shield, Aluminum Windings, UL Class 220C Insulation, NEMA Type 3R Ventilated Floor Mount, DOE 2016 Compliant, UL/cUL, 63/73 Series (Vanguard)

Dongan

63-30-407

63-30-407

Transformer, 30kVA, Primary: 380VAC, Secondary: 208Y/120VAC, 60Hz, 3 Phase, Electrostatic Shield, Aluminum Windings, UL Class 220C Insulation, NEMA Type 3R Ventilated Floor Mount, DOE 2016 Compliant, UL/cUL, 63/73 Series (Vanguard)

Dongan

63-30-594

63-30-594

Transformer, 30kVA, Primary: 380VAC, Secondary: 240VAC, 60Hz, 3 Phase, Electrostatic Shield, Aluminum Windings, UL Class 220C Insulation, NEMA Type 3R Ventilated Floor Mount, DOE 2016 Compliant, UL/cUL, 63/73 Series (Vanguard)
