Product image is representative only, please verify specifications.
8120200520
Alt: N1200-HBD RS485 USB
Process Controller, Heater Break Detec., 48x48mm
- Weight:
- 0.50 LBS
- Minimum Purchase:
- 1 unit
Our NOVUS 1200 is a process controller that was designed for high performance and demanding application.
This series had the highest sampling rate among competitors; 55 samples per second. Thanks a its self-adaptive PID algorithm, the N1200 responds quickly and accurately even in the most complex temperature profiles.
The N1200 is an easy-to use model and is fully configurable by keyboard or USB using the NOVUs free configuration software.
This series allows ramp and soak temperature profiles customization, programming up to 20 user-configured recipes or up to 180 segments.
The N1200 accepts most industrial sensors and signals and the housing is made of flame retardant material.
Features Include:
- Accepts thermocouples J, K, N, R, T, S, B, E, Pt100 RTD, 0-20 mA, 4-20 mA, 50 mV, 0-5 Vdc and 0-10 Vdc
- Internal resolution: 32,767 levels (15 bits)
- Displayed resolution: 12,000 levels
- Dual LED display: red upper display for PV, 10 mm high; green lower display for SV, 8 mm high
- Sampling: up to 55 measurements/second
- Control output update: up to 20 ms
- Isolated 4-20 mA output with up to 32,000 resolution levels (15 bits), 550 ohms maximum load
- 2 SPST relays 1,5 A / 240 Vac/dc and 1 SPDT relay (optional)
- 3 A/250 Vac/dc
- Power supply: 100 to 240 Vac/dc, 50/60 Hz; optional 24 Vac/dc
- Maximum consumption: 9 VA
- Operating environment: 5 to 50 °C, 30 to 80% RH
- Dimensions: 48 x 48 x 110 mm
- Panel cutout: 45.5 x 45.5 mm (1.79 x 1.79 in
- Approximate weight: 150 g (5.29 oz.)
Protection:
- NEMA 4 front bezel (IP65), PC UL94 V-2
- Case IP20, ABS + PC UL94 V-0
- Rated CE and UL.
Need More Information?
- Novus N1200 Series Universal Process Controller Flyer
- Novus N1200 Series Universal Process Controller Operation Manual
- Novus N1200 Series Universal Process Controller Quick Guide
- Novus N1200 Series Universal Process Controller Communication Protocol
- Novus N1200 Series Heater Break Detector Option Datasheet
