Available Now! PS5R-VD24
Available Now! (7 in stock)

PS5R-VD24

Alt: PS5R-V Series

$63.07

Power Supply, Compact, DIN-Rail Mount, 60W, 24V, 2.5 Amp, UL508/1310, RoHS, Class 1, Div 2

Weight:
1.00 LBS
Minimum Purchase:
1 unit
Adding to cart… The item has been added
5 year warranty!
Description

The PS5R-V series takes all the best features from the previous generation (PS5R) and improves them!

This high efficiency series includes expanded operating temperature range, a MTBF of up to 900,000 hours plus numerous approvals and certifications.

  • Spring up screw terminals, fused inputs and overload protection
  • DIN rail or direct surface mountable (6 directions!)
  • Universal input of 85 to 264VAC
  • No derating
  • 5 year warranty!
  • All models under 100W are UL1310, Class 2 approved
  • Class 1 Division 2 for hazardous locations
  • SEMI F47 for use in sensitive equipment applications (208VAC input)
  • RoHS compliant

Series Features Include:

  • Rated Input Voltage (Single-phase two-wire): 100 to 240V AC (Voltage range: 85 to 264V AC/100 to 370V DC) (Load ≤ 80% at 100-105V DC)
  • Wide operating temperature range
  • Spring-up terminals accept ring & fork terminals
  • Approved for use in Class I Division 2 hazardous locations
  • Can be installed in 6 directions
  • Overcurrent protection with auto-reset
  • Meets SEMI F47 Sag Immunity (208V AC input)
  • Protection Rating: IP20 (EN60529)
  • RoHS compliant
