11001315
Alt: OPDK 14P5901/S35A
$966.60
Retroreflective Sensor, Polarization Filter, Pulsed Red Laser Diode, Laser Class 1, 10-30VDC, 10m Actual Range Sb, Teach-in, PNP, Light/Dark Operate, M8 4-Pin Connector, 14.8 x 43 x 31mm (WxHxD), Plastic (ASA/MABS), -10 to +50°C, IP67
- Weight:
- 0.25 LBS
- Minimum Purchase:
- 1 unit
Description
The Baumer OPDK retroreflective sensors detect objects that interrupt the light beam between the sensor and a reflector, combining emitter and receiver in one housing for single-sided installation.
Key Features
- Pulsed red laser diode light source
- Laser class 1
- Actual range Sb up to 10m depending on model
- 10-30VDC supply voltage
- PNP output
- Light operate, dark operate and light/dark operate output function depending on model
- Adjustment by Teach-in
- M12 4-Pin Connector, 2m 4-Pin Cable and M8 4-Pin Connector connection versions
- Compact 14.8 x 43 x 31mm housing
- Plastic (ASA/MABS) housing
- Operating temperature -10 to +50°C
- IP67 protection
