DJMP0202

DJMP0202

$1,198.78

Motor, 20hp, 3600 RPM, 254/256JM Frame, 230/460VAC, 3 Phase, ODP, IP22

Weight:
250.00 LBS
Minimum Purchase:
1 unit
Adding to cart… The item has been added
NEMA Premium close-coupled pump motors built for commercial-duty applications
Description

The Teco-Westinghouse Rolled Steel JP/JM NEMA Premium series is a lightweight, close-coupled pump motor line built on a durable rolled steel frame for commercial-duty pump, HVAC, and compressor applications where dirt and moisture are minimal.

Key Features

  • NEMA Premium efficiency, inverter-duty rated
  • Open Drip Proof (ODP) enclosure
  • NEMA JM (footless) or JP (footed) close-coupled pump frame configurations
  • Rolled steel frame and main conduit box
  • Grounding terminal inside the main conduit box
  • 1.15 continuous service factor at 60 Hz
  • Class F insulation, Class B temperature rise
  • NEMA Design B torque
  • Designed for 40°C ambient temperature
  • Suited to HVAC, compressors, and general commercial-duty pump applications
