Teco Westinghouse
DHP2004R
Motor, 200hp, 1800 RPM, 445T Frame, 460VAC, 3 Phase, ODP, NEMA Premium Efficiency, IP22
$9,991.26
7 available from manufacturer (as of 10/12/2026)
DHP2004
$9,127.53
Motor, 200hp, 1800 RPM, 445T Frame, 460VAC, 3 Phase, ODP, NEMA Premium Efficiency, IP22
- Weight:
- 1,577.00 LBS
- Minimum Purchase:
- 1 unit
Description
The Teco-Westinghouse Cast Iron ODP NEMA Premium series is a general-purpose, open drip-proof motor line built on a durable cast iron frame for reliable continuous duty in indoor and protected industrial environments.
Key Features
- NEMA Premium efficiency
- Open Drip Proof (ODP) enclosure
- Cast iron frame and end brackets
- Rolled steel main conduit box, rotatable in 90-degree increments, F1 mounted
- Grounding terminal inside the main conduit box
- 1.15 continuous service factor at 60 Hz
- Class F insulation, Class B temperature rise
- NEMA Design B torque
- Designed for 40°C ambient temperature and elevations up to 3,300 ft
- Bi-directional rotation with a 1045 carbon steel shaft
Accessories
Check any items you would like to add to your cart, and then tap the ‘Add Selection to Cart’ button.
Teco Westinghouse
DHP20045
Motor, 200hp, 1800 RPM, 445T Frame, 460VAC, 3 Phase, ODP, NEMA Premium Efficiency, IP22
$9,458.28
