03036OP3EFP284TSC-W4
Weg

03036OP3EFP284TSC-W4

Alt: This Item Replaced 03036OP3EFP284TSC

$1,809.37

Motor, 30hp, 3600rpm, 2-Pole, 3 Phase, 230/460VAC, 60Hz, 284TSC Frame, High Efficiency, IC01 ODP, Cast Iron, Footed/C-Flange, W40, Fire Pump, IP23, (Cannot Ship UPS, Drop Ship Only via Truck)

Weight:
336.03 LBS
Minimum Purchase:
1 unit
Adding to cart… The item has been added
Compact WEG W40 ODP high efficiency motors for industrial applications
Description

The WEG W40 High Efficiency open drip proof (ODP) motor platform is designed as a compact, lightweight solution for industrial applications.

Key Features

  • Compact, lightweight ODP platform
  • IC01 open drip proof cooling
  • Ratings from 20hp to 400hp
  • 3600, 3000, 1800, 1500 rpm synchronous speed options
  • Three phase design
  • Voltage options include 230/460V, 200-208/400V, 575V, 460V, 380-400-415V
  • Open drip proof (ODP) enclosure
  • High Efficiency
  • Frame sizes from 254/6T to 447/9TS
  • Mounting options include footed and footed with C-face
  • IP23 degree of protection
