Weg
01512ET3E284TC-W22
Motor, 15hp, 1200rpm, 3 Phase, 208-230/460V, 284/6TC, NEMA Premium Efficiency TEFC, Footed/C Face, Heavy Duty
$2,944.36
Product image is representative only, please verify specifications.
00318ET3EBM182T-W22
Alt: 13500906, W22 Brake Motor
$1,826.28
Motor, 3hp, 1800rpm, 4 Pole, 182/4T Frame, 230/460V, 60Hz, 3 Phase, NEMA Premium Efficiency IC411 - TEFC, Cast Iron, Footed/No Flange, F-1 Mounting, Left Position Terminal Box, IP55
- Weight:
- 118.00 LBS
- Minimum Purchase:
- 1 unit
Description
WEG is a global manufacturer of electric motors, variable frequency drives, soft starters and controls. The controls line includes contactors, starters, circuit breakers and much more.
WEG Electric Corp. USA, located in Duluth, GA, has a number of distribution centers including one right here in the Chicago area.
Features Include:
- Frame: 182/4T
- Output: 3 HP
- Number of Poles: 4
- Frequency: 60 Hz
- Rated speed: 1800 rpm
- Slip: 2.22 %
- Rated voltage: 230/460 V
- Rated current: 7.82/3.91 A
- No load current: 30.0/15.0 A
- L. R. Amperes: 63.3/31.7 A
- Mounting: Foot-mounted
- Flange: Without
- Mounting: F-1
- Terminal box: Left position
- Enclosure: IC411 - TEFC
- Rated torque: 8.95 ft.lb
Technical Information:
- Weg 00318ET3EBM182T-W22 Motor Datasheet
- Weg W22 Three-Phase Electrical Motor Brochure
- Weg W22 Three-Phase Electric Motor Technical Catalog
- Weg Three-Phase General Purpose Motor Catalog
- Weg Three-Phase General Purpose Motor Instruction Manual
- Weg Three-Phase General Purpose Motor Operation Manual
- Weg Product Number Configuration
- Weg Standard Product 2020 Catalog
- Warranty Terms for Weg Automation Products
- 'Extend to a 3 Year Warranty' Form
