07518ET3E365T-W22
Alt: 11166657
$7,747.45
Motor, 75hp, 1800rpm, 3 Phase, 208-230/460V, 364/5T, NEMA Premium Efficiency TEFC, Footed/No Flange, Heavy Duty
- Weight:
- 1,036.20 LBS
- Minimum Purchase:
- 1 unit
Description
Motor, 3 Phase, 75hp, 1800rpm, 208-230/460V, Footed, Heavy Duty, W22 Platform
Features Include:
Output Rating:
- 75 HP (55 kW)
Rated Voltage:
- 208-230/460 V
Rated Current:
- 186-168/84.1 A
Synchronous Speed:
- 1800 rpm
Rated Speed:
- 1775 rpm
Rated Torque:
- 219 ft.lb
Number of Poles: 4
Frequency: 60 Hz
No-Load Current: 51.7-60.0/30.0 A
Starting Method:
- Direct On Line
Mounting:
- Foot-Mounted, F-1
Enclosure:
- IC411 - TEFC
Frame: 364/5T
Frame Material: Cast Iron
Need More Information?
- Weg W22 Three-Phase Electrical Motor Brochure
- Weg W22 Three-Phase Electric Motor Technical Catalog
- Weg Three-Phase General Purpose Motor Catalog
- Weg Three-Phase General Purpose Motor Instruction Manual
- Weg Three-Phase General Purpose Motor Operation Manual
- Weg Product Number Configuration
- Weg Standard Product 2020 Catalog
- Warranty Terms for Weg Automation Products
- 'Extend to a 3 Year Warranty' Form
