GSB632PC40
Alt: MCB UL1077 C 2P 40A
$22.10
Supplementary Circuit Protector, UL1077, 2 Pole, C-Curve, 40A Overload Range, 277VAC, 5kA, DIN Rail Mount, IP20, GSB63 Series
- Minimum Purchase:
- 1 unit
Description
Series Features Include:
- Protection of circuits against short circuit and overload currents
- UL1077 supplementary protection
- 1, 2, 3 and 4 pole arrangements
- 13 amperage sizes up to 63Amps
- Insulation Voltage: 500 VAC
- Rated Voltage: Single Phase: 277 VAC / Three-Phase: 480Y/277VAC
- Rated Frequency: 50/60 Hz
- Rated Breaking Capacity: 5,000 A
- Mounting: Vertical on DIN rail EN 60715 (35mm)
- Connection: Line-in on top, line-out on bottom
- Icn of 5kA
- Bimetallic element for small overloads
- Magnetic element for short circuit protection
- B, C, D trip characteristics
- Full line of bus bars and connectors
- Auxiliary contact, alarm switch and shunt release accessories
Technical Information:
