300-100-66
Werma

300-100-66

Alt: 300.100.66, 30010066

$199.37

LED Light Strip, 200mm, 4-Color RGB LED, 24VDC, Clip Mount, M12 5-Pin Connector, Aluminum/PC/Stainless Steel Housing, Up to 2 Segments, Integrated Buzzer, -30°C to +50°C, IP54/IP65

Weight:
0.39 LBS
Minimum Purchase:
1 unit
Adding to cart… The item has been added
Segmented LED status lighting with a built-in audible alert
Description

The WERMA LineLIGHT Fusion Segment A series adds a built-in audible signal to the segmented LineLIGHT Fusion RGB LED light strip, combining multi-segment visual signaling with acoustic alerts in one flush-mounted module.

Key Features

  • Segmented illumination allows the light strip to display multiple states or a scaling progress indication
  • 4-color RGB LED illumination (red, yellow, green, blue) selectable per segment
  • Integrated buzzer with pulse-tone acoustic signal for combined optical/audible alerts
  • Flush, gap-free housing design that minimizes dirt-collecting edges and openings
  • Aluminum, polycarbonate, and stainless steel construction
  • Screw-in clip mounting for built-in panel installation
  • Pre-assembled M12 5-pin connector for simplified wiring
  • Operates on 24VDC
  • Operating temperature range of -30°C to +50°C
  • Rated IP54/IP65 for use in demanding industrial environments

Certifications

  • CE
  • RoHS
  • WEEE
  • UKCA
