Description
Series Features Include:
- Front panel installation according to IEC 947-5-1 D30
- 1 to 8 actuating directions with spring return switches or combined
- One changeover contact with tab connector 2.8 x 0.5 IEC 760 for each actuating direction
- Center position switch
- Pushbutton in handle
- Actuating side with/without bellow: IP 65
- Switching current (at 24V): min. 12 mA
- Switching voltage: min. 10 V
- Weight Approx.: 0.2 kg
- Connection: Tab connector 2.8 x 0.5 IEC 760
- Switching principle: Snap-action contact element, design ES 584
- Rated impulse withstand voltage Uimp: 2.5 kV
- Rated insulation voltage Ui: 250 V
- Utilization category AC 15: 230V 4A
- Utilization category DC 13: 24V 2A
- Switching voltage: DC 10 - 50 V
- Material: Contact: Silver alloy, Housing: thermoplastic/aluminum, Switching lever: stainless steel, Bellows: elastomer, black
Technical Information:
