018662

Series Features Include:

• Front panel installation at rear or with front plate
• Switch with actuating direction 1 and pushbutton with actuating direction 2-4
• One changeover contact with screw terminal for each actuating direction
• Bellows
• Housing material: Reinforced thermoplastic/aluminum, Bellows: elastomer, black
• Switching lever material: Galvanized steel
• Contact material Silver alloy
• Weight: Approx. 0.7kg
• Degree of protection on the front with bellows: IP 65
• Mounting type: 1x hole 42 and 8x 4.5 for M4
• Number of monitoring contacts: 4
• Connection: Screw terminal
• Switching principle: Changeover contact ZA, IEC 947-5-1
• Rated insulation voltage Ui: 250 V
• Rated impulse withstand voltage Uimp: 2.5 kV
• Utilization category AC-15: 230V 10A
• Utilization category DC-13: 24V 4A
• Switching current, min. at 24 V: 50mA
• Switching voltage, min.: 24 V



Technical Information:

• Euchner Joystick Switches Catalog
