ARK-1220L-S6A2

Features Include:

• Audio Main System: Realtek ALC888S, High Definition Audio, Line-out, Mic-in
• Intel Atom E3940 Quad Core SoC turbo burst up to 1.8 GHz
• Operational Temperature: With extended temp. peripherals: -30 ~ 70 C (-22 ~ 158F) w/ turbo burst off with 0.7 m/s air flow; With 2.5 inch hard disk: 0 ~ 40 °C (32 ~ 104°F) with 0.7 m/s air flow
• Chipset: Intel HD Graphics 500, CPU integrated
• Dual Display: HDMI1 + HDMI2
• Graphic Engine: Gen9 Low Power; 18 Execution Units Media Codec Supported: H.264, MPEG2, MVC, VC-1, WMV9, H.265 / HEVC, VP8, JPEG / MJPEG, 3D HW Acceleration: OpenGL 4.4, DirectX* 12, OpenCL* 2.0
• HDMI: HDMI1 : 3840 x 2160 @ 30Hz; HDMI2 : 3840 x 2160 @ 30Hz
• Digital I/O: 8-bit Programmable DIO (Optional)
• Serial Port: 2 x RS-232/422/485 with auto flow control, COM2 with 5V/12V power supply
• Shock During Operation: With SSD: 30 G, IEC 60068-2-27, half sine, 11 ms duration
• Dimensions (W x H x D): 53.5 x 158 x 114 mm (2.11" x 6.22" x 4.49")
• 2 x Intel GbE and 4 x USB 3.0
• 1 x full-size mPCIe with SIM holder and 1 x M.2 2230 for WIFI
• 1 x 2.5” SATA III SSD and 1 x full-size mSATA*
• 12V ~ 28V wide range power input
• Advantech WISE-PaaS support
• No RED Certification

Technical Information:

• Advantech ARK-1220L A2 DIN-Rail Fanless Box PC Technical Data
• Advantech ARK-1220L A2 DIN-Rail Fanless Box PC User Manual
