Baumer
IFRM 03N1505/CS35L
Inductive Proximity Sensor, Ø3x12mm, Flush, 10-30VDC, 0.8mm Range, NPN NO, M8 Connector, IP67
$442.09
7 available from manufacturer (as of 10/28/2026)
IFRM 03P1505/CS35L
Alt: 10140294
$442.09
Inductive Proximity Sensor, Ø3x12mm, Flush, 10-30VDC, 0.8mm Range, PNP NO, M8 Connector, IP67
- Weight:
- 0.50 LBS
- Minimum Purchase:
- 1 unit
Description
Inductive Proximity Sensor, Ø3x12mm, Flush, 10-30VDC, 0.8mm Range, PNP NO, M8 Connector, IP67
Features Include:
- Nominal Sensing Distance Sn: 0.8 mm
- Mounting Type: Flush
- Hysteresis: 2 - 20% of Sr
- Output Indicator: 3 port LED red
- Switching Frequency: < 3 kHz
- Voltage Supply Range +Vs: 10 - 30 VDC
- Current Consumption Max. (no load): 12 mA
- Voltage Drop: < 2 VDC
- Output Current: < 100 mA
- Material (sensing face): POM
- Housing Material: Stainless Steel
