Simpson Electric has been manufacturing analog and digital panel meters, as well as test instruments and equipment, since 1927.



They are well known for their 260 volt-ohm-millimeter and remain proudly made in the USA.

Series Features Include:

• System: 3-phase, 3 or 4 wire unbalanced load
• Voltage: 120/208, 120/240, 277/480, 63/110
• Measurement Range: 20% to 120%
• Current: 5 amp from external CTs Fully Isolated
• Measurement Range: 5% to 120%
• Operating Frequency: 45 to 65 Hz
• Harmonics: Up to the 30th harmonic
• Input Loading Voltage: Less than 0.1VA per phase
• Input Loading Current: Less than 0.1VA per phase
• Overload Voltage: x2 for 2 seconds max.
• Overload Current: x40 for .5 second max.
• Auxiliary Supply Standard: 115V±15% 45-65Hz
• Auxiliary Supply Optional: 230V±15% 45-65Hz
• Display: Custom backlit supertwist LCD 3 lines of .47”
• General: (12mm) digits plus .15” (3.8mm) legends
• Bezel: 3.79” x 3.79” (w/ .29” lip)
• Depth: 3.35”
• Panel Cutout: 3.62” x 3.62”

Technical Information:

• Simpson Electric GIMA Three Phase Digital Panel Meters Technical Data
• Simpson Electric GIMA Multi-Function Electricity Meter Operator's Manual
• Simpson Electric GIMA MODBUS Communication Options Module Instruction Manual
• Simpson Electric Three-Phase Current Transformers Accessories Technical Data
