Alt: AZM170-B25-L-G2, BETAETIGER AZM 170-B25-L-G2
Door-Handle Actuator, G2 Version, Left-Hinged Door, for Schmersal EX-AZM 170 Solenoid Interlocks with Latching (ZRK) Function, No Protruding Actuator, No Separate Door Handle Needed, 8mm Square for Custom Handles
The Schmersal AZM 170-B25 door-handle actuators combine the door handle and actuator for Schmersal AZM 170 solenoid interlocks with latching (ZRK) function, including the EX-AZM 170-02ZRK used in ATEX Zones 2 and 22. Because the actuator does not protrude and no separate door handle is needed, they simplify guard-door hardware on hinged doors.
Schmersal
Actuator, Straight, Rigid, Stainless Steel, for Schmersal EX-AZM 170 Solenoid Interlocks, 140mm Min. Actuating Radius via Narrow Edge, 200mm on Hinged Guards, Suited for Sliding Doors, Mounting Screws Not Included
Schmersal
Actuator, Angled, Stainless Steel (V2A), for Schmersal EX-AZM 170 Solenoid Interlocks, 140mm Min. Actuating Radius via Narrow Edge, 200mm on Hinged Guards, Hinge Axis 13mm Above Switch, Suited for Sliding Doors
Schmersal
Actuator, Angled, Stainless Steel, for Schmersal EX-AZM 170 Solenoid Interlocks, 140mm Min. Actuating Radius via Narrow Edge, 200mm on Hinged Guards, Hinge Axis 25mm Above Switch, Suited for Sliding Doors, Mounting Screws Not Included
Schmersal
Actuator, Straight, Stainless Steel, for Schmersal EX-AZM 170 Solenoid Interlocks, 140mm Min. Actuating Radius via Narrow Edge, 200mm on Hinged Guards, Hinge Axis 37.5mm Above Switch, Suited for Sliding Doors, Mounting Screws Not Included
Schmersal
Actuator, Straight, Rubber Mounted for Vibration Damping, Stainless Steel (V2A), for Schmersal EX-AZM 170 Solenoid Interlocks, 200mm Min. Actuating Radius on Hinged Guards, Suited for Sliding Doors, 2Nm Max. Mounting Torque
