DIB02CD48150MV
DIB02CD48150MV
DIB02CD48150MV
Carlo Gavazzi

DIB02CD48150MV

Alt: Manufacturer Minimum Order 5 Pieces, (DIB 02 C D48 150MV)

$144.80

Monitoring Relay, 24-48VAC/DC, SPDT, 6 to 150mV AC/DC and 0.4 to 4 Vp AC (MI or MP Range), Single Phase, DIN Rail Mount, Manufacturer Minimum Order 5 Pieces, Price per Piece

Minimum Purchase:
5 units
Adding to cart… The item has been added
If you do not see the green 'in stock' circle on this item, Carlo Gavazzi is quoting 12 to 14 weeks for new orders (items may arrive sooner from our existing stock orders). We are happy to offer similar items with shorter lead times or from stock!
DIB02CD48150MV
DIB02CD48150MV
DIB02CD48150MV
DIB02CD48150MV
Description
Monitoring Relay, 6-150mV AC/DC & 0.4-4V AC, 1-Phase, 24-48VAC/DC, DIN Rail Mount

Features Include:

  • TRMS AC/DC over or under current monitoring relays
  • Current measuring through external shunt or CT
  • Selection of measuring range by DIP-switches
  • Measuring ranges from 6 to 150 mV AC/DC and 0.4 to 4 Vp AC (MI or MP range)
  • Adjustable current on relative scale
  • Adjustable hysteresis on relative scale
  • Adjustable delay function (0.1 to 30 s)
  • Programmable latching or inhibit at set level
  • Output: 8 A SPDT relay N.D. or N.E. selectable
  • For mounting on DIN-rail in accordance with DIN/EN 50 022 (DIB02) or plug-in module (PIB02)
  • 22.5 mm Euronorm housing (DIB02) or 36 mm plug-in module (PIB02)
  • LED indication for relay, alarm and power supply ON
  • Galvanically separated power supply
Accessories
!
✓
