M2N175T3L
Alt: 1100230
$741.63
Molded Case Circuit Breaker, UL489, M2N Frame, 3-Pole, 175A, 100kA @ 240VAC, Adjustable Thermal/Magnetic, Lug Terminals
- Weight:
- 4.41 LBS
- Minimum Purchase:
- 1 unit
Description
NOARK M Series Molded Case Circuit Breakers (MCCBs) provide overload and short-circuit protection for cables, control panels, motors, and branch circuits across six frame sizes (M1 through M6, 15A-1200A), and are designed to withstand a wide -40 to +70°C temperature range for reliable performance in demanding industrial applications.
Key Features
- Available frame sizes M1 (up to 150A) through M6 (up to 1200A)
- Interrupting ratings up to 100kA at 480Vac depending on frame/trip unit
- Thermal-magnetic trip protection (adjustable on select frames)
- Lug line/load side terminal connections
- 5-year limited warranty from NOARK Electric
Certifications
- UL 489
