B1H1C7
Alt: 1002105
$23.73
Miniature Circuit Breaker, UL489, 1-Pole, 7A, C-Curve, 277VAC, 10kA, Box Lugs, DIN Rail Mount
- Weight:
- 1.00 LBS
- Minimum Purchase:
- 1 unit
Description
NOARK B1 Series miniature circuit breakers mount on standard 35mm DIN rail and provide thermal-magnetic overcurrent protection for branch-circuit and supplementary protection applications, with a contact position indicator and trip-free design that cannot be defeated by holding the handle ON.
Key Features
- Thermal-magnetic inverse time-delay overcurrent protection
- 35mm DIN rail mounting
- Contact position indicator (red/green)
- Trip-free design; captive screws cannot be lost
- 5-year limited warranty from NOARK Electric
Certifications
- UL 1077
- UL 489
- IEC 60947-2
- CSA C22.2 No. 235
