820KCG00DK
Alt: DOCK N20K48
$9.00
DOCK N20K48
- Weight:
- 0.25 LBS
- Minimum Purchase:
- 1 unit
Description
Since 1982, NOVUS Automation has manufactured devices for data acquisition, temperature and process control as well as signal conditioning.
NOVUS is headquartered in southern Brazil with sales offices and warehouses in the US as well.
Series Features Include:
- Display: LCD type, alphanumeric with 11 segments.
- Input Type: Thermocouple J, K, T, E, S, N, R, B, Pt100, 0-50 mV, 0-5 V, 0-10 V, 0-20 mA and 4-20 mA.
- PID Features: PWM, Auto tune
- Control Action: 1 Loop (Heat or Cool)
- Output Control: 1 Pulse and up to 1 Relay
- Ramp & Soak: 20 Programs, 9 Segments
- Sampling Period: 18 ms
- Communication: RS485 Modbus RTU (optional)
- Power Consumption: 10 VA
- Special Functions: Soft-Start, PID Loop Break, Ramp and Soak event, 4 Alarms (9 alarm types) and Timer Function
- Configuration: Software NOVUS QuickTune, QuickTune Mobile, via USB (micro-B type) or Bluetooth
- Power Supply: 100-240 Vac/dc or 12-24 Vdc (Optional)
- Operate Conditions: Temperature: -20 to 60 °C (-4 to 140 °F), Humidity: 80 % @ 30 °C (86 °F)
- Front Panel: IP65, Polycarbonate (PC) UL94 V-2
- Enclosure: 48x48 (DIN 1/16), ABS+PC UL94 V-0
