Ex9CA09D11E

Ex9CA09D11E

Alt: 1322000

$107.95

Safety Contactor, Standard, FVNR, 9 Amp, DC, 1NO+1NC, 48V, 3-Pole, Ex9CA Series

Weight:
1.00 LBS
Minimum Purchase:
1 unit
Adding to cart… The item has been added
Description

The Noark Ex9CA safety contactors offers unique features for safety control circuits with current ratings up to 38 amp.

  • The normally closed (NC) auxiliary contact is a mirror contact to the main contacts and is mechanically linked to the normally open (NO) auxiliary contacts. This allows for optimal design selections in SRP/CS*
  • Applications for the Ex9CA include e-stops, light curtains, safety gates and safety interlocks
  • Equipped with a permanent transparent cover that prevents manual operation and provides easy identification of the device status
  • They are available with either AC or DC operating coils. DC coil models are equipped with integrated surge suppression
  • Each unit is clearly identified by the prominent red front cover marked with a mechanically linked contact symbol
  • They install easily on 35mm DIN rail or on panels
  • The Ex9CA is back by a 5-year limited warranty

Features Include:

  • Direct Current (DC) Voltage: 48 V
  • Contacts: 1 Normally Closed (NC) / 1 Normally Open (NO)
  • Current: 9 A
  • Rated Insulation Voltage: 690V
  • Number of Poles: 3
  • Rated Impulse Withstand Voltage U imp: 6kV
  • Positively guided mirror contacts/mechanically linked contacts according to IEC/UL60947-4-1 Annex F, IEC/UL60947-5-1 Annex L
  • Mirror contacts/ mechanically linked symbol on the side of auxiliary block
  • Fixed transparent anti-dust cover for easy identification of the device action and prevents the manual operation
  • AC or DC operating coils
  • Integrated surge suppression on DC coil models
  • Mounting: Mounts on DIN rail 35 mm or panel
