IR30.P18S-F50.PV1Z.7BCV
Baumer

IR30.P18S-F50.PV1Z.7BCV

Alt: 11171575

$141.69

Inductive Proximity Sensor, M30, Flush, 6-36VDC, 18mm Range Sn, PNP, NO/NC Complementary, Enhanced Distance (GammaProx), 2m Cable, 30 x 50mm Cylindrical Threaded Nickel Plated Brass Housing, -25 to +75°C, IP67

Weight:
0.50 LBS
Minimum Purchase:
1 unit
Adding to cart… The item has been added
Baumer IR30 GammaProx inductive proximity sensor with extended sensing range
Description

The Baumer IR30 inductive proximity switch with enhanced sensing distance (GammaProx) detects metal objects without contact and offers an increased sensing distance compared with standard inductive sensors, with triple sensing distance on selected models.

Key Features

  • Enhanced sensing distance (GammaProx); triple sensing distance depending on model
  • Nominal sensing distance 18 mm
  • Flush mounting
  • NPN or PNP switching output, NO/NC Complementary depending on model
  • Supply voltage 6-36 VDC
  • Connection via 2 m cable or M12 connector depending on model
  • Cylindrical threaded housing in nickel plated brass
  • Operating temperature -25 to +75 °C
  • Protection class IP67

Accessories
Check any items you would like to add to your cart, and then tap the ‘Add Selection to Cart’ button.
Add Selection to Cart

Baumer

IR30.P18S-F35.PV1Z.7BCV

Inductive Proximity Sensor, M30, Flush, 6-36VDC, 18mm Range Sn, PNP, NO/NC Complementary, Enhanced Distance (GammaProx), 2m Cable, 30 x 35mm Cylindrical Threaded Nickel Plated Brass Housing, -25 to +75°C, IP67

$160.80

Baumer

IR30.P18S-F50.NV1Z.7BCV

Inductive Proximity Sensor, M30, Flush, 6-36VDC, 18mm Range Sn, NPN, NO/NC Complementary, Enhanced Distance (GammaProx), 2m Cable, 30 x 50mm Cylindrical Threaded Nickel Plated Brass Housing, -25 to +75°C, IP67

$141.69

Baumer

IR30.P18S-F45.PV1Z.7BO

Inductive Proximity Sensor, M30, Flush, 6-36VDC, 18mm Range Sn, PNP, NO/NC Complementary, Enhanced Distance (GammaProx), M12 Connector, 30 x 45mm Cylindrical Threaded Nickel Plated Brass Housing, -25 to +75°C, IP67

$160.80

Baumer

IR30.P18S-F35.NV1Z.7BCV

Inductive Proximity Sensor, M30, Flush, 6-36VDC, 18mm Range Sn, NPN, NO/NC Complementary, Enhanced Distance (GammaProx), 2m Cable, 30 x 35mm Cylindrical Threaded Nickel Plated Brass Housing, -25 to +75°C, IP67

$160.80

Baumer

IR30.P18S-F60.PV1Z.7BO

Inductive Proximity Sensor, M30, Flush, 6-36VDC, 18mm Range Sn, PNP, NO/NC Complementary, Enhanced Distance (GammaProx), M12 Connector, 30 x 60mm Cylindrical Threaded Nickel Plated Brass Housing, -25 to +75°C, IP67

$141.69
