103037332
Alt: AZM40B-I2-ST-1P2P-PH
Electronic Solenoid Interlock Switch (RFID), Individual Coding (Reteachable), Plan Housing Finish, 20H x 40W x 119.5Hmm, Recommended Actuator AZM40-B1-PH to be Ordered Separately
- Weight:
- 1.00 LBS
- Minimum Purchase:
- 1 unit
The Schmersal AZM40 is a compact, non-contact RFID solenoid interlock switch for monitoring and locking movable machine guards such as hinged or sliding doors. Its flat, low-profile housing mounts directly to 40mm profile systems, and RFID coding provides tamper resistance without the wear of a mechanical actuator. The actuator can approach the switch anywhere within a 180 degree angle, simplifying alignment on rotating or sliding guards.
Key Features
- Non-contact RFID sensing technology reduces mechanical wear and tampering risk
- Available in standard, individually coded (single), and individually coded (reteachable) versions
- 180 degree actuator approach angle with 2 degree maximum angular misalignment
- Bi-stable solenoid interlock holds its last position if power is lost
- Status LEDs visible from 3 sides
- Supports series-wiring of multiple units on a single safety circuit
- 24VDC operating voltage (stabilized PELV power supply)
- M12, 8-pin connector for quick installation
- IP66/IP67/IP69 rated die-cast light alloy and glass-fiber reinforced plastic housing
- Compatible with the AZM40-B1 actuator (ordered separately)
Certifications
- Type 4 interlocking device per EN ISO 14119
- Suitable for safety functions up to Performance Level e (Category 4) per EN ISO 13849-1
- Suitable for SIL 3 applications per EN IEC 61508
- cULus Listed
