Proximity Sensors

Proximity sensors detect the presence or absence of objects without any physical contact. Inductive proximity sensors require a metal target, capacitive can handle non-metal and liquids.

Style:
Product Price Rating Action
  • pf_nbb0.8-5gm25-e2__92650.jpg

    Pepperl+Fuchs

    053491

    Inductive Proximity Sensor, Ø5mm, Flush, 3-Wire DC, 10-30VDC, 0.8mm Range, PNP NO, 0 to 200mA, Reverse Polarity Protected, 2m PVC Cable, Stainless Steel Housing, PC Sensing Face, Ambient Temperature: -25 to 70 °C (-13 to 158 °F), IP67

  • pf-nbb-series-proxsensor-general__66446.jpg

    Pepperl+Fuchs

    326161-0006

    Inductive Proximity Sensor, Flush (Shielded), 5-36VDC, 4mm Rated Operating Distance, NPN, NO, DC Output Polarity, M12 3 Pin Connector, Brass, White Bronze Coated Housing, Green PBT Sensing Face, 2 Self Locking Nuts, -40 to +85°C Ambient/Sto

  • Baumer_IF08.D02S-F16.UA1Z.7WCV_Primary.jpg

    Baumer

    IF08.D02S-F16.UA1Z.7WCV

    Inductive Distance Sensor, Subminiature, Flush, 12-30VDC, 0-2mm Measuring Distance Sd, Voltage Output, 0-10VDC, 2m PVC Cable, 8 x 16mm Rectangular Shape, Die-Cast Zinc Nickel Plated Housing, 10 to +60°C, IP67, Suggested Alternative for IWFM

  • baumer_-_ifbr_-_d_-_inductive_prox_sensor_2__19577.jpg

    Baumer

    IFBR 17P17T1/S14L-9

    Inductive Proximity Sensor, Hygienic Design, Quasi-Flush, 6-30VDC, 8mm Nominal Sensing Distance Sn, PNP, NO, M12 Connector, 17 x 60mm, Smooth Cylindrical Type, Stainless Steel Housing, LCP Sensing Face, IP68/69K and ProTect+

  • baumer_-_l_-_prox_sensor__98159.jpg

    Baumer

    IFFM 08N1703/O1L

    Inductive Proximity Sensor, Subminiature, Flush, 6-36VDC, 2mm Sensing Distance Sn, NPN, NO, 2m Cable, Die-Cast Zinc Nickel Plated Housing, PBT Sensing Face, Rectangular 8 x 20mm, -25° to +75°C, IP67

  • pepperl_fuchs_-_cbn15-f64-e2_-_capacitive_sensor__82649.jpg

    Pepperl+Fuchs

    310470

    Capacitive Proximity Sensor, 3-Wire DC, 15mm Range, PNP, NO, 2m PUR Cable, Flat Housing, IP67, Returns of This Item Must Be Approved by Manufacturer

Proximity sensors detect the presence or absence of objects without any physical contact. Inductive proximity sensors require a metal target, capacitive can handle non-metal and liquids.
