$95.20$95.20 -
Baumer
FPDK 10N5135
Retroreflective Sensor, Miniature, Pulsed Red LED, 10-30VDC, 3.5m Actual Range Sb, 4m Nominal Range Sn, Potentiometer, 240°, NPN, Light/Dark Operate, 2m 4-Pin Cable, 27 x 10.4 x 16.3mm (HWD), Plastic ASA Housing, PMMA Optics, -20° to +65°C,
$267.29$267.29 -
Baumer
FPDK 10P5130
Retroreflective Sensor, Miniature, Pulsed Red LED, 10-30VDC, 3.5m Actual Range Sb, 4m Nominal Range Sn, PNP, Light/Dark Operate, 2m 4-Pin Cable, 27 x 10.4 x 16.3mm (HWD), Plastic (ASA) Housing, PMMA Optics, -20° to +65°C, IP65
$257.20$257.20 -
$240.09$240.09 -
Takex
GN-M2CRPN-J
Photoelectric Sensor, Amplifier, Polarized, PNP, Red LED, IP67, Compact, M8 Connector
$96.90$96.90 -
Available Now!
Available Now!Takex
GS20SN
Photoelectric, NPN, Diffuse Reflective, 300mm Rng, 12-24VDC, Light ON/Dark ON, 2m Cable, IP67
$116.45$116.45 -
$578.80$578.80 -
$302.20$302.20 -
Baumer
O500.GR-GW1T.72O
Diffuse Sensor, Background Suppression, 10-30VDC, 60-550mm Sensing Distance Tw, 30-600mm Sensing Range Tb, Pulsed Red LED, 630 nm, Push-Pull, qTeach, Light/Dark Operate, M12 4-Pin Connector, Plastic Housing, PMMA Optics, 45 x 18 x 32mm (HWD
$213.80$213.80 -
Baumer
O500W.RP-GW1B.PVO
Retroreflective Sensor, Polarization Filter, Washdown Design, 10-30VDC, 7.5 Actual Range Sb, 8m Nominal Range Sn, Pulsed PinPoint LED, 630 nm, Push-Pull, qTeach/Remote, Light/Dark Operate, M12 4-Pin Connector, Stainless Steel Housing, PMMA
$258.80$258.80 -
Baumer
OM30-L0550.HV.TXN
Photoelectric Distance Sensor, 50-550mm, 12-28VDC, RS485, Modbus RTU, Teach-In, Line Beam, Laser Class 2, Pulsed Red Laser Diode, Die-Cast Zinc, M8 4-pin Connector, IP67, -10 to +50°C Operating Temperature, 49 x 40.3 x 13.6mm (HWD)
$1,725.60$1,725.60 -
Takex
F85RNP-J
Fiber Optic Sensor, Dual Display, 12-24VDC, NPN/PNP Dual Output, Dark On/Light On, Four-Element (ALGainP) LED, M8 Connector, 0.065 - 4.000ms Response Time, IP40, Simple Teaching, Easy to Use, Replacement for F71RPN-J
$133.24$133.24
Photoelectric sensors detect the distance, absence or presence of an object. These sensors are great for sensing long distances and detecting most materials.
How Does a Photoelectric Sensor Work?
Generally a photoelectric sensor consists of the following:
- Transmitter - emits the light beam
- Receiver - detects the light beam and converts it to an electrical signal
Photoelectric sensors detect changes in the light beam caused by the presence/absence, movement or properties of an object.
Types of Photoelectric Sensors:
- Through-Beam (Thru-Beam)
- Transmitter and receiver are two separate units that are directly opposite of each other. The sensor detects when an objects breaks the light beam
- Great for long distance detection
- Ideal for conveyors, counting or monitoring door openings
- Retroreflective (Reflective Mode)
- Transmitter and receiver are in one housing; light beam is reflected back by a reflector. Detection is triggered when an object breaks the beam.
- Medium range detection and easier to install than a through beam
- Ideal for package detection and pallet positioning
- Diffuse (Proximity Mode)
- The transmitter and receiver in one housing; the sensor detects light reflected directly off the target object (no reflector needed)
- Best for short range applications
- Ideal for detecting objects on assembly lines, verifying presence or checking fill level
- Specialized Types:
- Background Suppression: Can ignore objects beyond a set distance, focuses close range
- Color or Contrast Sensors: Detects specific colors or contrast differences
- Distance Measuring Sensors: Mesaure the distance to an object
Categories Related to Photoelectric Sensors:
- Stack lights - signal towers visually communicate the data or alerts that the photoelectric sensors are generating
- Smart relays - photoelectric sensors provide input signals which can process the data and control outputs
- Pushbuttons and estops - if your sensor detects a fault, an operator can use a pushbutton to reset the system
- HMIs - HMIs can dispay the data from the photoelectric sensor which allows you to monitor processes
