$109.76$109.76 -
Autonics
BX700-DFR-T
Diffuse Reflective Sensor, 24-240VAC/DC, 700mm Sensing Range, Infrared LED, Built-in Sensitivity, Light On/Dark On Switchable, Relay Output, Timer Function, ABS Case, Acrylic Lens, Terminal Block, -25 to +55°C Ambient Temperature, IP66
$110.00$110.00 -
$56.00$56.00 -
$59.00$59.00 -
$56.00$56.00 -
$84.00$84.00 -
$56.00$56.00 -
Autonics
BYS500-TDT1,2
Photoelectric Sensor, Thru-Beam, Vertical Type, Dark On, NPN Output, 12-24VDC
$56.00$56.00 -
Baumer
CFDM 20N1500/S35L
Capacitive Proximity Sensor, Flush, 10-30VDC, 5mm Nominal Sensing Distance Sn, 20mA, NPN, NO, M8 Connector, 20 x 35mm, Brass Nickel Plated Housing, -25 to +75°C, IP65
$643.00$643.00 -
Baumer
CFDM 20N3500/S35L
Capacitive Proximity Sensor, Flush, 10-30VDC, 5mm Nominal Sensing Distance Sn, 20mA, NPN, NC, M8 Connector, 20 x 35mm, Brass Nickel Plated Housing, -25 to +75°C, IP65
$643.00$643.00 -
Baumer
CFDM 20P1500/S35L
Capacitive Proximity Sensor, Flush, 10-30VDC, 5mm Nominal Sensing Distance Sn, 20mA, PNP, NO, M8 Connector, 20 x 35mm, Brass Nickel Plated Housing, -25 to +75°C, IP65
$643.00$643.00 -
Baumer
CFDM 20P3500/S35L
Capacitive Proximity Sensor, Flush, 10-30VDC, 5mm Nominal Sensing Distance Sn, 20mA, PNP, NC, M8 Connector, 20 x 35mm, Brass Nickel Plated Housing, -25 to +75°C, IP65
$643.00$643.00
Photoelectric sensors detect the distance, absence or presence of an object. These sensors are great for sensing long distances and detecting most materials.
How Does a Photoelectric Sensor Work?
Generally a photoelectric sensor consists of the following:
- Transmitter - emits the light beam
- Receiver - detects the light beam and converts it to an electrical signal
Photoelectric sensors detect changes in the light beam caused by the presence/absence, movement or properties of an object.
Types of Photoelectric Sensors:
- Through-Beam (Thru-Beam)
- Transmitter and receiver are two separate units that are directly opposite of each other. The sensor detects when an objects breaks the light beam
- Great for long distance detection
- Ideal for conveyors, counting or monitoring door openings
- Retroreflective (Reflective Mode)
- Transmitter and receiver are in one housing; light beam is reflected back by a reflector. Detection is triggered when an object breaks the beam.
- Medium range detection and easier to install than a through beam
- Ideal for package detection and pallet positioning
- Diffuse (Proximity Mode)
- The transmitter and receiver in one housing; the sensor detects light reflected directly off the target object (no reflector needed)
- Best for short range applications
- Ideal for detecting objects on assembly lines, verifying presence or checking fill level
- Specialized Types:
- Background Suppression: Can ignore objects beyond a set distance, focuses close range
- Color or Contrast Sensors: Detects specific colors or contrast differences
- Distance Measuring Sensors: Mesaure the distance to an object
Categories Related to Photoelectric Sensors:
- Stack lights - signal towers visually communicate the data or alerts that the photoelectric sensors are generating
- Smart relays - photoelectric sensors provide input signals which can process the data and control outputs
- Pushbuttons and estops - if your sensor detects a fault, an operator can use a pushbutton to reset the system
- HMIs - HMIs can dispay the data from the photoelectric sensor which allows you to monitor processes
