Pepperl+Fuchs
295670-100146
Photoelectric Retroreflective Sensor with Polarization Filter for Clear Object Detection, Returns of This Item Must Be Approved by Manufacturer
$204.96$204.96 -
Pepperl+Fuchs
295670-100147
Photoelectric Sensor, Clear-Object, 8m, LED, 10-30VDC, 4-in-1 Output, IO-Link, M12 5-Pin Connector
$204.96$204.96 -
Pepperl+Fuchs
295670-100190
Photoelectric Retroreflective Sensor with Polarization Filter for Clear Object Detection, Returns of This Item Must Be Approved by Manufacturer
$204.96$204.96 -
Pepperl+Fuchs
295670-100191
Photoelectric Sensor, Clear-Object, 8m, LED, 10-30VDC, 4-in-1 Output, IO-Link, M12
$204.96$204.96 -
Pepperl+Fuchs
295670-100200
Photoelectric Triangulation Sensor with Background Suppression, IO Link, 10-30VDC, 300mm Range, Light/Dark On, M12 4-Pin 90° Rotatable Connector, 15mmW x 50.6mmH x 41.7mmD, IP67/69/69K, Returns of This Item Must Be Approved by Manufacturer
$193.76$193.76 -
Pepperl+Fuchs
295670-100228
Photoelectric Sensor, BGS, 600mm, Laser, 10-30VDC, 4-in-1 Output, IO-Link, M12
$256.48$256.48 -
Pepperl+Fuchs
295670-100242
Photoelectric Sensor, BGS, 600mm, Laser, 10-30VDC, 4-in-1 Output, IO-Link, M12
$256.48$256.48 -
Pepperl+Fuchs
297897
Distance Photoelectric Sensor, Analog Output, IOLink, Pulse Ranging Technology (PRT), Laser
$635.04$635.04 -
Pepperl+Fuchs
302636
Photoelectric Thru-Beam Sensor (Receiver), Returns of This Item Must Be Approved by Manufacturer
$107.52$107.52 -
Pepperl+Fuchs
302637
Photoelectric Thru-Beam Sensor (Emitter), Returns of This Item Must Be Approved by Manufacturer, Returns of This Item Must Be Approved by Manufacturer
$86.24$86.24 -
Pepperl+Fuchs
314850
Sensor, Thru-Beam, Pair Consists of: LA28-LAS-F1-7675 (Emitter) & LK28-LAS-F1-Z-7675 (Receiver), 120m Detection Range, Red Light, Light/Dark On, 88mmH x 25.8mmW x 65.5mmD, IP67, Returns of This Item Must Be Approved by Manufacturer
$534.24$534.24 -
Pepperl+Fuchs
418066
Print Mark Contrast Sensor, 10-30VDC, 300mm Range, Laser Diode, 650nm, Light On/Dark On Switchable, Push-Pull O/P, PNP, M12 5 Pin Connector, PC (Makrolon), Glass Optics, -10 to +50°C Ambient Temperature, 33 x 85.6 x 60.8mm (WHD), IP67
$898.24$898.24
Photoelectric sensors detect the distance, absence or presence of an object. These sensors are great for sensing long distances and detecting most materials.
How Does a Photoelectric Sensor Work?
Generally a photoelectric sensor consists of the following:
- Transmitter - emits the light beam
- Receiver - detects the light beam and converts it to an electrical signal
Photoelectric sensors detect changes in the light beam caused by the presence/absence, movement or properties of an object.
Types of Photoelectric Sensors:
- Through-Beam (Thru-Beam)
- Transmitter and receiver are two separate units that are directly opposite of each other. The sensor detects when an objects breaks the light beam
- Great for long distance detection
- Ideal for conveyors, counting or monitoring door openings
- Retroreflective (Reflective Mode)
- Transmitter and receiver are in one housing; light beam is reflected back by a reflector. Detection is triggered when an object breaks the beam.
- Medium range detection and easier to install than a through beam
- Ideal for package detection and pallet positioning
- Diffuse (Proximity Mode)
- The transmitter and receiver in one housing; the sensor detects light reflected directly off the target object (no reflector needed)
- Best for short range applications
- Ideal for detecting objects on assembly lines, verifying presence or checking fill level
- Specialized Types:
- Background Suppression: Can ignore objects beyond a set distance, focuses close range
- Color or Contrast Sensors: Detects specific colors or contrast differences
- Distance Measuring Sensors: Mesaure the distance to an object
Categories Related to Photoelectric Sensors:
- Stack lights - signal towers visually communicate the data or alerts that the photoelectric sensors are generating
- Smart relays - photoelectric sensors provide input signals which can process the data and control outputs
- Pushbuttons and estops - if your sensor detects a fault, an operator can use a pushbutton to reset the system
- HMIs - HMIs can dispay the data from the photoelectric sensor which allows you to monitor processes
